ACM1552D-CW WalletMate II Boost with USB cable

ACM1552D-CW WalletMate II Boost with USB cable
Availability: In stock info icon
×

Stock availability on SmartcardFocus

Coming soon - We are arranging supplies of this product. You will not be able to order just yet. Check back soon, or contact us to find out more about timescales.
In stock - This product is on the shelf in our UK warehouse and ready for use. If you place an order you can expect immediate dispatch. Depending on courier, delivery is typically next day in the UK, or 3-5 days in the US.
In stock* - This product is on the shelf in our UK warehouse, but requires some configuration or assembly before dispatch, which can add a day or two to delivery times, depending on product and order quantities.
Low stock - This product is on the shelf in our UK warehouse. If your order quantity is small you will not notice any difference from 'in stock' product. If you are ordering larger quantities, there could be delays while we wait for additional stock to arrive. Contact us to discuss options for part delivery.
Stock on the way - This product is usually on the shelf in our UK warehouse, but we have sold out and are waiting for new stock to arrive. You can still order but delivery will be slower than usual. Contact us to find out more about timescales.
Ordered on demand - We have a regular supplier but will only order when an order is placed with us and can then advise on delivery timescales. Please note that 'Ordered on demand' items are not returnable.
Contact us - There are currently supply issues with this product. You will not be able to order the product. Contact us to find out more about the nature of any issues and for advice on alternatives.
Not available - There are no plans to restock this item, it will shortly be removed from the site.
£ 75.02
(£ 90.02 inc VAT)
Units
Per Unit
1+
£ 75.02
250+
Contact us
Prices shown are per unit, excluding VAT and delivery.
Please contact us for volume and reseller pricing.
This ACM1552D-CW WalletMate II Boost reader board has a built-in antenna. It is based on an ACM1552U which has been enhanced, so that it can support the use of mobile wallet passes. It has been certified for Apple VAS (value-added services ECP1.0), Apple ECP2.0 access control and Google Smart Tap applications, such as loyalty schemes, tickets, and staff or student IDs. The ACM1552D-CW is a reader board with a detachable USB cable. An optional RS-232 cable is also available.

The ACM1552 module from ACS is a 13.56 MHz contactless smartcard reader board that supports ISO 14443 type A and B cards, MIFARE, FeliCa, ISO 15693 and ISO 18092-compliant NFC cards and tags. This is the latest evolution of the popular ACM1252. Private keys are stored inside the secure element for Apple VAS and Google Smart Tap. This model also includes a SAM slot to enable a higher-level of security in contactless and NFC transactions. It is designed to integrate into vending machines, kiosks and gaming systems.

The ACM1552 supports modes including card reader/writer, card emulation and keyboard emulation (using a free software download, with the USB interface only).

The ACM1552 is CCID and PC/SC compliant, for maximum interoperability with various different devices and applications.

The basic ACS VAS Test Tool for Windows/Linux is available (from ACS) on request, to allow you to test NFC mobile wallet passes on this reader board.

In order to control the operation of this reader board within an application you will need to develop software. Your application itself will also require approvals before mobile passes can be obtained. If you are developing a mobile wallet application do please contact us and we will be happy to offer advice or help you refine your requirements.

ACM1552D-CW WalletMate II Boost with USB cable



Credential type(s): Contactless
NFC modes: Read and Write, Keyboard emulation (with USB only), Card emulation
Form factor: Reader module with built-in antenna
Cable: USB Type-A detachable. Optional RS-232 detachable cable available separately.
OS support: Windows; Linux; Mac OS; Android

Contactless Card Interface:

Contactless interface standard: ISO 14443 Type A and B; ISO 18092 NFC, ISO 15693
Contactless credential types: MIFARE, FeliCa
Contactless operating frequency: High (13.56MHz)
Data transmission protocol: T=CL
Contactless operating distance: Up to 70mm (2.8in) depending on tag type
Contactless read/write speed: 106/212/424/848kbps ISO14443 or 26kbps ISO15693

Contact (SAM) Card Interface:

Contact interface standard: ISO 7816 Class A, standard SIM-sized slot
Contact read/write speed: 13.4kbps to 1250kbps
Clock frequency: 5MHz
Data transmission protocol: T=0, T=1

Host Interface:

Host interface protocol: USB or RS-232
USB connector: 5pin, Molex KK 254 wire-to-board header compatible
USB host data transmission speed (wired): 12 Mbps (USB 2.0 full speed) compatible with USB 3.0
Serial connector: 5pin, JST B5B-XH-A compatible
RS-232 host data transmission speed (wired): 9.6 kbps, 19.2kbps, 38.4kbps, 57.6kbps
RS-232 default settings: 115200bps, 8 data bits, no parity, 1 stop bit

Other Features:

Status indicator: 1 x programmable LED (blue and green), 1 x programmable buzzer (monotone)
Firmware in-field upgradeable: Yes
Libraries and tools: Apple VAS API, Google Smart Tap API, CT-API; ACS VAS Test Tools with API; a Software Development Kit is available to purchase separately from ACS.

Certifications:

Manufacturer's warranty: 1 year
MTBF: 500 000hrs
Standards: J-LIS, Apple VAS (ECP1.0 and ECP2.0), Google Smart Tap, CE, UKCA, FCC, VCCI, RoHS, REACH, WEEE, MIC

Physical:

Dimensions: 106.6 x 67 x 16mm (4.2 x 2.6 x 0.63in)
Antenna size: 65 x 60mm (2.6 x 2.4in)
Weight (±1g): 20g (0.7oz) without cable, 68g (5.9oz) with USB cable
Cable lengths supplied: 1m (39in) USB cable

Power:

Supply voltage: 5V DC
Operating current: 300mA (max)
Battery power option: No

Environment:

Operating temperature: -20 to 70degC (-4 to 158degF)
Operating humidity: Up to 90% RH (non-condensing)

Manufacturer's part number: ACM1552D-CW + ACM1552D-CBAU01

Country of origin: China
HSF code: 8542390000

Manufacturer: ACS

Connection Method: USB
