| Technical Specifications | |
| Host interface | USB 2.0 CCID (USB 1.1 / 3.0 compliant) 12 Mbps (USB2.0 full speed) |
| Smart Card Interface | |
| Supported Standards | ISO 7816 Part 1 to 4 |
| Supported Tag ICs | All major ISO 7816 compliant Smart Card IC support |
| Protocols | T=0, T=1 |
| Interface speed | up to 600 kBit/s (depending on card); TA1=97 |
| Clock frequency | ISO 7816 compliant up to 5 MHz, Operates up to 16 MHz |
| Supported smart card types | 5V, 3V and 1.8V, ISO 7816 Class A/B/C |
| Power to smart card | 60mA in Class A; 55mA in Class B; 35mA in Class C |
| Smart card detection | Card present switch / Automatic power on/off / Short Circuit protection |
| Contactless Interface | |
| Supported standards | ISO 14443 A&B Part 1-4 |
| Protocols | T=CL, MIFARE |
| Supported card chips | MIFARE (Classic, Ultralight, Ultralight C, MIFARE PLUS, DESFire, DESFire EV1 2/4/8k), FeliCa, Calypso |
| Data transfer rate | 106/212/424/848 kbit/s depending on card IC |
| Reading distance | Up to 70 mm depending on card chip type and card antenna size |
| Antenna | Integrated |
| Operating Conditions | |
| PC/SC driver | Windows XP/Vista/7/8 (32&64Bit) / Windows Server 2003/2008/2012 / Windows CE 6.0, 7.0 MacOS 10.5.x, 10.6.x, 10.7.x, 10.8.x Linux 2.4.x, 2.6.x (32&64Bit) |
| Software | PC/SC API CT-API (through wrapper on top of PC/SC) Synchronous-API (through wrapper on top of PC/SC) |
| Operating Conditions | |
| Power supply | USB Bus powered |
| Power consumption | < 120 mA, excluding smart card/SAM;< 185 mA, with smart card/SAM;<500 μA in Standby Mode |
| Dimension | 113x93x92mm / 4.449x3.661x3.622 Inch |
| Weight | 179 g ± 5% / 0.39 lb ± 5% |
| Operating temperature range | 0° to +50°C / +32 to +122 F |
| Status indicator | LED |
| Firmware in-field upgradeable | Yes |
| Certifications / Compliances | |
| Systems / Standards | ISO 7816, USB 2.0 Full Speed, CCID, Microsoft WHQL |
| Regulatory / Environmental | CE, FCC, UL94, RoHS2, REACH |
